Maintenance
Maintenance operations
7
EN
31
Lenze ¯ MA 12.0014 ¯ 1.0
Oil−level inspection
Check the oil level by means of the displayed dipsticks. Manufacture them according to
the mounting position.
Model: Dipsticks for g500−B240
A, 3-stufig
A, 2-stufig
B
C
D
E
F
